Reactive Polyurethane Hot Melt Adhesive (PUR)
Reactive polyurethane hot melt adhesive is a solvent-free product. It possesses the high initial strength of hot melt adhesives, while its subsequent reaction performance provides good strength and weather resistance.
1
Flexible packaging
Flexible packaging
| 粘扣带复合 |
| 1. Characteristics: Low temperature flexibility, high anti-slip characteristics | |||||||||||||||||||
| Characteristic：Low-temperature flexibility and high resistance to slip | |||||||||||||||||||
| 2. Application: Safety shoe midsoles, outsoles | |||||||||||||||||||
| Application：：For safety shoes | |||||||||||||||||||
| 3. Typical characteristics of PU matrix | |||||||||||||||||||
| Product name | Appearance | Viscosity | Density | Packaging | |||||||||||||||
| Name of products | Apperance | Viscosity (cps at 40℃) | Density (g/cm3 at 40℃) | Package(kg) | |||||||||||||||
| HT-8950 | Liquid or wax-like | 1300~2100 | 1.140~1.180 | 18 | |||||||||||||||
| liquid or waxy solid | |||||||||||||||||||
| F-2980 | Liquid or wax-like | 0 | 1.180~1.200 | 20 | |||||||||||||||
| liquid or waxy solid | |||||||||||||||||||
| ◎Ideal storage temperature for materials: below 25°C | |||||||||||||||||||
| 4. Material preheating | |||||||||||||||||||
| HT-8950 | F-2980 | ||||||||||||||||||
| 60-70℃ preheating for 6~8h | 60-70℃ preheating for 8~12h | ||||||||||||||||||
| Preheated at 60-70℃ for 6~8h | Preheated at 60-70℃ for 8~12h | ||||||||||||||||||
| 5. Molding conditions and reaction parameters | |||||||||||||||||||
| Item | Material temperature | Mixing ratio | Cream time | Rise time | Foam density | Mold temperature | Demolding time | ||||||||||||
| Items | HT/F Materials temperature(℃) | Mixing ratio (HT+SM)/F(By weight) | Cream time(s) | Rise time(s) | Free foam density (g/cm3) | Mold temperature(℃) | Demolding time( min) | ||||||||||||
| Technical parameters | 40~45/40~45 | Outsole | Midsole | 7~10/6-7 | 45~55/35~40 | Outsole | Midsole | 40~45 | 3~5 | ||||||||||
| Parameter | |||||||||||||||||||
| 100/58~60 | 100/66~68 | 0.6~0.7 | 0.27~0.35 | ||||||||||||||||
| ◎The addition amount of catalyst SM-2 is outsole: the addition amount of SM-2 is 220±5g/18kg. Midsole: the addition amount of SM-2 is 320±5g/18kg. | |||||||||||||||||||
| ◎Water and hardener are added according to actual needs The adding content of water and hardener should added to the reality | |||||||||||||||||||
| Outsole: Water H2O water addition amount is 10±2 g/18kg | |||||||||||||||||||
| Midsole: Water H2O water addition amount is 70±5 g/18kg | |||||||||||||||||||
| 6. Product properties | |||||||||||||||||||
| Item | Molding density | Hardness | Tensile strength | Elongation | Tear strength | DIN abrasion resistance | SRB slip resistance | ||||||||||||
| Items | Molded density (g/cm3) | Hardness (Shore A) | Tensile strength (kg/cm2) | Elongation(%) | Tear strength (kg/cm) | DIN abrasion resistance(mm3) | SRB slip resistance |
||||||||||||
| Physical property value | Outsole | Midsole | Outsole | Midsole | Outsole | Midsole | Outsole | Midsole | Outsole/Midsole | Outsole | Outsole/Midsole | ||||||||
| Physical properties | 0.9 ~1 | 0.45~0.55 | 55~62 | 45~50 | ≥70 | ≥40 | ≥500 | ≥400 | ≥80/≥30 | ≤150 | ≥0.13(Heel) ≥0.18(Flat) |
||||||||
| ◎This physical property data was obtained from testing a 6mm thick test piece. | |||||||||||||||||||
| These physical data are acquired by testing a sample of 6mm thick. | |||||||||||||||||||
| ◎Free foam density will vary according to the season (temperature, humidity). | |||||||||||||||||||
| Free rise density may vary with temperature &humidity. | |||||||||||||||||||
| ◎Demolding time will be prolonged as the thickness of the finished product increases. | |||||||||||||||||||
| Demold time may be prolonged with the increase of sold thickness. | |||||||||||||||||||
| ◎The above data is for reference only, and the specific data is subject to actual operation. If other physical property indicators are required, please contact us. | |||||||||||||||||||
| Data listed are just for reference。 The detail data are subject to operation.If other request on physical properties,please contact us. | |||||||||||||||||||
| 布布复合 |
| 1. Characteristics: high adhesion, low temperature resistance | |||||||||||||||||||
| Characteristic： | |||||||||||||||||||
| 2. Application: Safety shoe midsoles, outsoles | |||||||||||||||||||
| Application： | |||||||||||||||||||
| 3. Typical properties of PU matrix | |||||||||||||||||||
| Product name | Appearance | Viscosity | Density | Packaging | |||||||||||||||
| Name of products | Apperance | Viscosity (cps at 40℃) | Density (g/cm3 at 40℃) | Package(kg) | |||||||||||||||
| HT-8850A | Liquid or wax-like | 1400~2000 | 1.140~1.180 | 18 | |||||||||||||||
| liquid or waxy solid | |||||||||||||||||||
| F-2180 | Liquid or wax-like | 300~500 | 1.180~1.200 | 20 | |||||||||||||||
| liquid or waxy solid | |||||||||||||||||||
| ◎Ideal storage temperature for materials: below 25°C | |||||||||||||||||||
| 4. Material preheating | |||||||||||||||||||
| HT-8850A | 60-70℃ preheating for 6~8h | ||||||||||||||||||
| Preheated at 60-70℃ for 6~8h | |||||||||||||||||||
| F-2180 | 60-70℃ preheating for 8~12h | ||||||||||||||||||
| Preheated at 60-70℃ for 8~12h | |||||||||||||||||||
| 5. Molding conditions and reaction parameters | |||||||||||||||||||
| Item | Material temperature | Mixing ratio | Cream time | Rise time | Foam density | Mold temperature | Demolding time | ||||||||||||
| Items | HT/F Materials temperature(℃) | Mixing ratio (HT+SM)/F(By weight) | Cream time(s) | Rise time(s) | Free foam density (g/cm3) | Mold temperature(℃) | Demolding time( min) | ||||||||||||
| Technical parameters | 40~45/40~45 | Outsole | Midsole | 7~10 | 45~55 | Outsole | Midsole | 35~40 | 6~7 | ||||||||||
| Parameter | |||||||||||||||||||
| 100/61.5~63.5 | 100/71.5~72.5 | 0.6~0.7 | 0.28~0.36 | ||||||||||||||||
| ◎The addition amount of Catalyst SM-2 is 220 | |||||||||||||||||||
| ◎Water and hardener are added according to actual needs The adding content of water and hardener should added to the reality | |||||||||||||||||||
| Outsole: Water H2O 20±5g/18kg | |||||||||||||||||||
| Midsole: Water H2O 50±5g/18kg | |||||||||||||||||||
| 6. Product properties | |||||||||||||||||||
| Item | Molding density | Hardness | Tensile strength | Elongation | Tear strength | Flexing resistance test | |||||||||||||
| Items | Molded density (g/cm3) | Hardness (Shore A) | Tensile strength (kg/cm2) | Elongation(%) | Tear strength (kg/cm) | Flexing Endurance Test at -10℃ | |||||||||||||
| Physical property value | Outsole | Midsole | Outsole | Midsole | Outsole | Midsole | Outsole | Midsole | Midsole | 50000 times without cracks | |||||||||
| Physical properties | 0.9~1.0 | 0.45~0.55 | 60~65 | 45~50 | >80 | >70 | >500 | >450 | >40 | 50000 times no crack | |||||||||
| ◎This physical property data was obtained from testing a 6mm thick test piece. | |||||||||||||||||||
| These physical data are acquired by testing a sample of 6mm thick. | |||||||||||||||||||
| ◎Free foam density will vary according to the season (temperature, humidity). | |||||||||||||||||||
| Free rise density may vary with temperature &humidity. | |||||||||||||||||||
| ◎Demolding time will be prolonged as the thickness of the finished product increases. | |||||||||||||||||||
| Demold time may be prolonged with the increase of sold thickness. | |||||||||||||||||||
| ◎The above data is for reference only, and the specific data is subject to actual operation. If other physical property indicators are required, please contact us. | |||||||||||||||||||
| Data listed are just for reference。 The detail data are subject to operation.If other request on physical properties,please contact us. | |||||||||||||||||||
| 布膜复合 |
| 1. Characteristics: Good hand feeling, good resilience, good dimensional stability | |||||||||||||||||
| Characteristic： | |||||||||||||||||
| 2. Application: Insoles, midsoles | |||||||||||||||||
| Application： | |||||||||||||||||
| 3. Typical properties of PU matrix | |||||||||||||||||
| Product name | Appearance | Viscosity | Density | Packaging | |||||||||||||
| Name of products | Apperance | Viscosity (cps at 40℃) | Density (g/cm3 at 40℃) | Package(kg) | |||||||||||||
| HT-6735 | Liquid or wax-like | 900~1500 | 1.060~1.140 | 18 | |||||||||||||
| liquid or waxy solid | |||||||||||||||||
| F-3210 | Liquid or wax-like | 200~500 | 1.160~1.180 | 19 | |||||||||||||
| liquid or waxy solid | |||||||||||||||||
| ◎Ideal storage temperature for materials: below 25°C | |||||||||||||||||
| 4. Material preheating | |||||||||||||||||
| HT-6735 | 60-70℃ preheating for 6~8h | ||||||||||||||||
| Preheated at 60-70℃ for 6~8h | |||||||||||||||||
| F-3210 | 60-70℃ preheating for 8~12h | ||||||||||||||||
| Preheated at 60-70℃ for 8~12h | |||||||||||||||||
| 5. Molding conditions and reaction parameters | |||||||||||||||||
| Item | Material temperature | Mixing ratio | Cream time | Rise time | Foam density | Mold temperature | Demolding time | ||||||||||
| Items | HT/F Materials temperature(℃) | Mixing ratio (HT+SM)/F(By weight) | Cream time(s) | Rise time(s) | Free foam density (g/cm3) | Mold temperature(℃) | Demolding time( min) | ||||||||||
| Technical parameters | 40~45/40~45 | 100/48~52 | 6~9 | 38~50 | 0.14~0.18 | 45~55 | 3~5 | ||||||||||
| Parameter | |||||||||||||||||
| ◎The addition amount of Catalyst SM-2 is 250±5g/18kg | |||||||||||||||||
| ◎The adding content of water is 100~130g/18kg | |||||||||||||||||
| 6. Product properties | |||||||||||||||||
| Item | Molding density | Hardness | Tensile strength | Elongation | Tear strength | ||||||||||||
| Items | Molded density (g/cm3) | Hardness (Shore C) | Tensile strength (kg/cm2) | Elongation(%) | Tear strength (kg/cm) | ||||||||||||
| Physical property value | 0.28~0.40 | 25~45 | ≥20 | ≥300 | 15 | ||||||||||||
| Physical properties | |||||||||||||||||
| ◎This physical property data was obtained from testing a 6mm thick test piece. | |||||||||||||||||
| These physical data are acquired by testing a sample of 6mm thick. | |||||||||||||||||
| ◎Free foam density will vary according to the season (temperature, humidity). | |||||||||||||||||
| Free rise density may vary with temperature &humidity. | |||||||||||||||||
| ◎Demolding time will be prolonged as the thickness of the finished product increases. | |||||||||||||||||
| Demold time may be prolonged with the increase of sold thickness. | |||||||||||||||||
| ◎The above data is for reference only, and the specific data is subject to actual operation. If other physical property indicators are required, please contact us. | |||||||||||||||||
| Data listed are just for reference。The detail data are subject to operation.If other request on physical properties,please contact us. | |||||||||||||||||
2
Textile
Textile
| 纸塑 |
| 1. Characteristics: Medium-low hardness, high adhesion, low temperature resistance | |||||||||||||||||
| Characteristic：Medium to low hardness, excellent adhesive property, low temperature resistance | |||||||||||||||||
| 2. Application: Cemented shoes, casual shoes, sneakers | |||||||||||||||||
| Application：For direct injection shoes，casual shoes and sport shoes | |||||||||||||||||
| 3. Typical characteristics of PU matrix | |||||||||||||||||
| Product name | Appearance | Viscosity | Density | Package | |||||||||||||
| Name of products | Apperance | Viscosity (cps at 40℃) | Density (g/cm3 at 40℃) | Package(kg) | |||||||||||||
| HT-5930G | Liquid or wax-like | 1000~1500 | 1.140~1.160 | 18 | |||||||||||||
| liquid or waxy solid | |||||||||||||||||
| F-2120 | Liquid or wax-like | 200~600 | 1.180~1.200 | 20 | |||||||||||||
| liquid or waxy solid | |||||||||||||||||
| ◎Ideal storage temperature for materials: below 25°C | |||||||||||||||||
| 4. Material preheating | |||||||||||||||||
| HT-5930G | 60-70℃ preheating for 6~8h | ||||||||||||||||
| Preheated at 60-70℃ for 6~8h | |||||||||||||||||
| F-2120 | 60-70℃ preheating for 8~12h | ||||||||||||||||
| Preheated at 60-70℃ for 8~12h | |||||||||||||||||
| 5. Molding conditions and reaction parameters | |||||||||||||||||
| Item | Material temperature | Mixing ratio | Cream time | Rise time | Foam density | Mold temperature | Demolding time | ||||||||||
| Items | HT/F Materials temperature(℃) | Mixing ratio (HT+SM)/F(By weight) | Cream time(s) | Rise time(s) | Free foam density (g/cm3) | Mold temperature(℃) | Demolding time( min) | ||||||||||
| Technical parameters | 40~45/40~45 | 100/62~64 | 7~10 | 40~50 | 0.21~0.25 | 40~45 | 3~5 | ||||||||||
| Parameter | |||||||||||||||||
| ◎The adding content of C-3 is 300±5g/18kg | |||||||||||||||||
| ◎The adding content of water is 80±5g/18kg; | |||||||||||||||||
| 6. Product properties | |||||||||||||||||
| Item | Molding density | Hardness | Tensile strength | Elongation | Tear strength | Flexing resistance test | |||||||||||
| Items | Molded density (g/cm3) | Hardness (Shore A) | Tensile strength (kg/cm2) | Elongation(%) | Tear strength (kg/cm) | Flexing Endurance Test at -20℃ | |||||||||||
| Physical property value | 0.41~0.45 | 33~40 | 20~30 | 500~700 | 25~45 | 50000 cycles without cracks | |||||||||||
| Physical properties | 50000 times no crack | ||||||||||||||||
| ◎This physical property data was obtained from testing a 6mm thick test piece. | |||||||||||||||||
| These physical data are acquired by testing a sample of 6mm thick. | |||||||||||||||||
| ◎Free foam density will vary according to the season (temperature, humidity). | |||||||||||||||||
| Free rise density may vary with temperature &humidity. | |||||||||||||||||
| ◎Demolding time will be prolonged as the thickness of the finished product increases. | |||||||||||||||||
| Demold time may be prolonged with the increase of sold thickness. | |||||||||||||||||
| ◎The above data is for reference only, and the specific data is subject to actual operation. If other physical property indicators are required, please contact us. | |||||||||||||||||
| Data listed are just for reference。 The detail data are subject to operation.If other request on physical properties,please contact us. | |||||||||||||||||
